| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Constant Voltage LED Drivers |
| Wattage | 40.8 | 40.8 | 40.8 | 40.8 |
| Input Voltage | 100 ~ 305VAC | 100 ~ 305VAC | 100 ~ 305VAC | 100 ~ 305VAC |
| Output Current | 3.4A | 1.7A | 3.4A | 1.7A |
| Output Voltage | 12V | 24V | 12V | 24V |
| Dimensions | 147 X 40 X 32 mm | 107 X 40 X 32 mm | 147 X 40 X 32 mm | 107 X 40 X 32 mm |
| Working Temperature | -25 ~ 90 C | |||
| Safety Standards | ENEC BS EN/EN61347-1, BS EN/EN61347-2-13(EL) appendix J suitable for emergency installations(DC input 176-280VDC); BS EN/EN62384, BIS IS15885(Part2/Sec13)(NOTE 14), GBT195101, GBT19510213, EAC TP TC 004,UL8750(Class P); CSA C22.2 No. 250.13-12 approved; Design refer to AS/NZS 61347-1, AS/NZS 61347-2-13 | |||
