Mean Well HLG-100H-B Series 0-10V Dimmable Constant Voltage LED Drivers 96W

Download Datasheet
Models:
  • HLG-100H-20B
  • HLG-100H-24B
  • HLG-100H-30B
  • HLG-100H-36B
  • HLG-100H-42B
  • HLG-100H-48B
  • HLG-100H-54B
Manufacturer: Mean Well
Type: Constant Voltage LED Drivers

HLG-100H-B Series Features:

IP67 design for indoor or outdoor installations

Built-in active PFC, PF>0.9 for 60% of load or higher

7 years warranty

Protections: Short circuit / Over current / Over voltage / Over temperature

Other features:

  • Universal AC input (up to 305VAC) / Full range
  • High efficiency up to 94%
  • Output current adjustable through output cable or internal potentiometer
  • Cooling by free air convection
  • Suitable for dry, damp and wet location
  • Suitable for LED lighting and street lighting applications
  • Meet 4KV surge immunity level (IEC61000-4-5)
  • Class 2 power unit
  • IP67 rated and built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)
Wattage 96 96 96 96 96 96 96
Input Voltage 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC 90~305VAC, 127~431VDC
Output Voltage 20 24 30 36 42 48 54
Output Voltage Options Single Single Single Single Single Single Single
Dimensions 220x 68x 38.8 220x 68x 38.8 220x 68x 38.8 220x 68x 38.8 220x 68x 38.8 220x 68x 38.8 220x 68x 38.8
Working Temperature -40~+70°C (Refer to "Derating Curve")
Safety Standards UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-2-13 approved; Design refer to UL60950-1, EN60950-1
EMC Standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024
