| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Constant Voltage LED Drivers |
Output voltage and C.C level can be adjusted through internal potentiometer
IP65 design for indoor or outdoor installations
Protections: Short circuit / Over current / Over voltage / Over temperature
Other features:
| Wattage | 480 | 540 | 560 | 600 | 600 | 600 | 600 | 600 | 600 |
| Input Voltage | 90~305VAC 127~431VDC | 90~305VAC 127~431VDC | 90~305VAC 127~431VDC | 90~305VAC 127~431VDC | 90~305VAC 127~431VDC | 90~305VAC 127~431VDC | 90~305VAC 127~431VDC | 90~305VAC 127~431VDC | 90~305VAC 127~431VDC |
| Output Voltage | 12 | 15 | 20 | 24 | 30 | 36 | 42 | 48 | 54 |
| Output Voltage Options | Single | Single | Single | Single | Single | Single | Single | Single | Single |
| DC output adjustment | 10.2~12.6 | 12.7~15.8 | 17~21 | 20.4~25.2 | 25.5~31.5 | 30.6~37.8 | 35.7~44.1 | 40.8~50.4 | 45.9~56.7 |
| Dimensions | 275x 145x 45 | 275x 145x 45 | 275x 145x 45 | 275x 145x 45 | 275x 145x 45 | 275x 145x 45 | 275x 145x 45 | 275x 145x 45 | 275x 145x 45 |
| Working Temperature | -40~+70°C (Refer to "Derating Curve") | ||||||||
| Safety Standards | UL8750, CSA C22.2 No. 250.13-12, EN61347-1, EN61347-2-13 independent, IP65 | ||||||||
| EMC Standards | Compliance to EN55015, EN61000-3-2 Class C (b '50% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024, light industry level (surge 4KV), criteria A | ||||||||
