MEAN WELL XLC-60 Series (constant voltage non dim) Non-dim Constant Voltage LED Drivers 60W

Models:	xlc-60-12 XLC-60-24 XLC-60-48 XLC-60-12-S XLC-60-24-S XLC-60-48-S
Manufacturer:	MEAN WELL
Type:	Constant Voltage LED Drivers

XLC-60 Series (constant voltage non dim) Features:

Spec	xlc-60-12	XLC-60-24	XLC-60-48	XLC-60-12-S	XLC-60-24-S	XLC-60-48-S
Wattage	60	60	60	60	60	60
Input Voltage	100 ~ 305VAC	100 ~ 305VAC	100 ~ 305VAC	100 ~ 305VAC	100 ~ 305VAC	100 ~ 305VAC
Output Current	5A	2.5A	1.25A	5A	2.5A	1.25A
Output Voltage	12V	24V	48V	12V	24V	48V
Dimensions	176 X 45 X 32 mm	176 X 45 X 32 mm	176 X 45 X 32 mm	176 X 45 X 32 mm	176 X 45 X 32 mm	176 X 45 X 32 mm
Working Temperature	-25~90℃
Safety Standards	UL8750(Class P), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13(EL) appendix J suitable for emergency installations(DC input 176-280VDC); BS EN/EN62384 , BIS IS15885(Part2/Sec13)(NOTE 13), GBT195101, GBT19510213, EAC TP TC 004 approved; Design refer to AS/NZS 61347-1, AS/NZS 61347-2-13
