MEAN WELL XLG-50-DA2 Series DALI 2 Constant Current LED Drivers 50W

Models:	XLG-50-L-DA2 XLG-50-H-DA2
Manufacturer:	MEAN WELL
Type:	Constant Current LED Drivers

XLG-50-DA2 Series Features:

XLG-50-DA2 series is a 50W AC/DC LED driver featuring the constant power mode output.

Features:

Constant power mode output
Metal housing design with functional ground
Built-in active PFC function
Class 2 power unit (except for L type)
Standby power consumption <0.5W
IP67 rating for indoor or outdoor installations
Surge protection with 6KV-4KV
DALI-2 dimming with minimum level 8%
India (EESL) version with input over voltage protection can survive input voltage stress of 440VAC for 48 hours
Typical lifetime >50000 hours
5 years warranty

Spec	XLG-50-L-DA2	XLG-50-H-DA2
Wattage	50	50
Input Voltage	90~305VAC	90~305VAC
Output Current	700mA	1050mA
Output Voltage	160V	60V
Dimensions	1056330mm (LWH)	1056330mm (LWH)
Working Temperature	Tcase=-40 ~ +85℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)
Safety Standards	UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC AS/NZS IEC BS EN/EN61347-1, AS/NZS BS EN/EN61347-2-13 independent, BS EN/EN62384; IP67; GB19510.1, GB19510.14, EAC TP TC 004 approved
EMC Standards	BS EN/EN55015(CISPR15) ,GB/T17743, BS EN/EN61000-3-2 ,GB/T17625.1, BS EN/EN61000-3-3
