Mean Well PCD-25 Series TRIAC Dimmable Constant Current LED Drivers 20–25W

Download Datasheet
Models:
  • PCD-25-350B
  • PCD-25-700B
  • PCD-25-1050B
  • PCD-25-1400B
Manufacturer: Mean Well
Type: Constant Current LED Drivers

PCD-25 Series Features:

AC phase-cut dimming

Constant current design

Protections: Short circuit/ Over temperature

Other features:

  • 180~295VAC input
  • Fully isolated plastic case
  • Built-in active PFC function
  • IP30 design
  • Class 2 power unit/ Pass LPS
  • Isolation class II, no F.G.
  • Cooling by free air convection
  • 3 years warranty
Wattage 20 25 25 25
Input Voltage 180~295VAC 180~295VAC 180~295VAC 180~295VAC
Output Current 350mA 700mA 1050mA 1400mA
Output Voltage 40~58 24~36 16~24 12~18
Output Voltage Options Single Single Single Single
Dimensions 84x 57x 29.5 84x 57x 29.5 84x 57x 29.5 84x 57x 29.5
Working Temperature -30~+50°C (refer to output derating curve)
Safety Standards UL8750, ENEC EN61347-2-13 approved
EMC Standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547
