The SPD-10-320S LED power supply SPD is mainly composed of MOV, GDT and flame-retardant shell. It has protective functions of surge, overflowing, thermal(thermal fusing) and flame retardant, used for the power supply protection of LED road lamp.
Features:
Series connection style
Line to Ground & Line to Line protected
10kA maximum discharge current (I max), 8/20us
Thermally protected
Double insulation cable wire
LED status indicator
IP67 design for indoor or outdoor installations
Suitable for LED driver surge protection with class I insulation
10KV surge protection capability
Spec
SPD-10-320S
Working Temperature
-40~+70°C
Safety Standards
Compliance to IEC61643-11: 2011, IEC61000-4-5: 2005
