MEAN WELL VFD-250P-48 Variable Frequency Drive

Name: MEAN WELL VFD-250P-48 | Variable Frequency Drive
SKU: VFD-250P-48

VFD-250P-48 Features:

VFD-2250P-48 is a variable frequency drive that can be controlled with external PWM controller.

Features:

4"x2" miniature size
20~55Vdc input
Controllable with external controller
Fanless design for no-noise and expanding life cycle
High surge current 200% up to 5 seconds
Protections: short circuit/OCP
Provided multiple sensors for control: current sensor-motor torque control, DC bus voltage sensor-OVP,UVP, Temperature sensor- OTP
-30~70℃ wide operating temperature
Suitable for three phase motor drive (BLDC, Induction motor, SynRM)
3 years warranty

Spec	VFD-250P-48
Wattage	250
Input Voltage	20~55VDC
Output Current	7.2
Output Voltage	Three phase line-to-line 0~34V, suit for 48V class motor
Dimensions	101.6x50.8x25.6mm
Working Temperature	-30 ~ +70℃(Refer to “Dreating Curve”)
Safety Standards	Design refer to EN618000-5
EMC Standards	EN 55015, EN 61000-3-2, EN 61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN 61547
