| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | DC-DC Power Supplies |
• DIP "1×1" package with industry standard pinout
• 8:1 (9~75Vdc) ultra-wide input range
• Operating temperature range -40 ~ +90℃
• No minimum load required
• Comply to BS EN/EN55032 radiated Class A without additional components
• High efficiency up to 88%
• Protections: Short circuit (Continuous) / Overload / Over voltage / UVLO
• 3KVdc I/O isolation
• Remote ON/OFF control
• Triming output (±10%)
• 3 years warranty
| Wattage | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Input Voltage | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V |
| Output Current | 0~3000mA | 0~3000mA | 0~1250mA | 0~1000mA | 0~625mA | ±0~1500mA | ±0~625mA | ±0~500mA |
| Output Voltage | 3.3V | 5V | 12V | 15V | 24V | ±5V | ±12V | ±15V |
| Dimensions | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) |
| Working Temperature | -40 ~ +90℃ (Refer to "Derating Curve") | |||||||
| Safety Standards | EAC TP TC 020/2011 approved | |||||||
| EMC Standards | BS EN/EN55032(CISPR32) | |||||||
