| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | DC-DC Power Supplies |
Features
• DIP "1×1" package with industry standard pinout
• 8:1 (9~75Vdc) ultra-wide input range
• Operating temperature range -40 ~ +90℃
• No minimum load required
• High efficiency up to 90%
• Protections: Short circuit (Continuous) / Overload / Over voltage / Over temperature / UVLO
• 1.5KVdc I/O isolation
• Remote ON/OFF control
• Triming output (±10%)
• 3 years warranty
| Wattage | 30 | 30 | 30 | 30 | 30 | 30 |
| Input Voltage | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V | 9 ~ 75V |
| Output Current | 0~7500mA | 0~6000mA | 0~2500mA | 0~2000mA | ±0~1250mA | ±0~1000mA |
| Output Voltage | 3.3V | 5V | 12V | 15V | ±12V | ±15V |
| Dimensions | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) | 25.4*25.4*10.2mm (1*1*0.4 inch) |
| Working Temperature | -40 ~ +90℃ (Refer to "Derating Curve") | |||||
| Safety Standards | EAC TP TC 020/2011 approved | |||||
| EMC Standards | BS EN/EN55032(CISPR32) | |||||
