| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Enclosed Power Supplies |
Universal AC input / Full range
Protections: Short circuit/ Overload/ Over voltage/ Over Temperature
Other features:
| Wattage | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Input Voltage | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC | 90~264VAC; 127~370VDC |
| Output Current | 3.0~20 / 0.0~20 /0.5~8.0 / 0.0~1.0 | 3.0~20 / 0.0~20 / 0.5~8.0 / 0.0~1.0 | 3.0~20 / 0.0~20 / 0.5~7.0 / 0.0~1.0 | 3.0~20 / 0.0~20 / 0.4~6.0 / 0.0~1.0 | 3.0~20 / 0.0~20 / 0.4~6.0 / 0.0~1.0 | 3.0~20 / 0.0~7.0 / 0.4~6.0 / 0.0~1.0 | 3.0~20 / 0.0~6.0 / 0.4~6.0 / 0.0~1.0 |
| Output Voltage | 5, 3.3, 12, -5 | 5, 3.3, 12, -12 | 5, 3.3, 15, -15 | 5, 3.3, 24, -12 | 5, 3.3, 24, -15 | 5, 12, 24, -12 | 5, 15, 24, -15 |
| Output Voltage Options | Quad | Quad | Quad | Quad | Quad | Quad | Quad |
| DC output adjustment | CH1 & 2: -5%~+10% rated output voltage | CH1 & 2: -5%~+10% rated output voltage | CH1 & 2: -5%~+10% rated output voltage | CH1 & 2: -5%~+10% rated output voltage | CH1 & 2: -5%~+10% rated output voltage | CH1 & 2: -5%~+10% rated output voltage | CH1 & 2: -5%~+10% rated output voltage |
| Dimensions | 215 x 115 x 50 | 215 x 115 x 50 | 215 x 115 x 50 | 215 x 115 x 50 | 215 x 115 x 50 | 215 x 115 x 50 | 215 x 115 x 50 |
| Working Temperature | -25~+70°C | ||||||
| Safety Standards | UL60950-1, TUV EN60950-1 approved | ||||||
| EMC Standards | EN55022 class B, EN61000-3-2,3 EN61000-4-2,3,4,5,6,8,11 | ||||||
