| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Enclosed Power Supplies |
Protections: Short circuit/ Overload/ Over voltage.
Other features:
| Wattage | 85 | 85 | 85 |
| Input Voltage | 88~264 AC, 125~373 DC | 88~264 AC, 125~373 DC | 88~264 AC, 125~373 DC |
| Output Current | 0~10, 0~4, 0~1, 0~1 | 0~10, 0~4, 0~1, 0~1 | 0~10, 0~4, 0~1.5, 0~1 |
| Output Voltage | 5, 12, -5, -12 | 5, 15, -5, -15 | 5, 12, 24, -12 |
| Output Voltage Options | Quad | Quad | Quad |
| DC output adjustment | CH1 -5%~+10% via pot. | CH1 -5%~+10% via pot. | CH1 -5%~+10% via pot. |
| Dimensions | 159 | 159 x 97 x 38 | 159 x 97 x 38 |
| Working Temperature | -25~+70°C | ||
| Safety Standards | UL60950-1, TUV EN60950-1 approved | ||
| EMC Standards | EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2, EN50082-2 | ||
