| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Enclosed Power Supplies |
Conformally Coated
Built-in active PFC function, PF >0.95
Protections: Short circuit/ Overload/ Over voltage/ Over Temp./ Fan alarm
Other features:
| Wattage | 2400 | 3000 | 3000 | 3000 |
| Input Voltage | 180~264VAC; 254~370VDC | 180~264VAC; 254~370VDC | 180~264VAC; 254~370VDC | 180~264VAC; 254~370VDC |
| Output Current | 0~200 | 0~125 | 0~62.5 | 0~62.5 |
| Output Voltage | 12 | 24 | 48 | 48 |
| Output Voltage Options | Single | Single | Single | Single |
| DC output adjustment | +/-10% rated output voltage | +/-10% rated output voltage | +/-10% rated output voltage | +/-10% rated output voltage |
| Dimensions | 278 x 177.8 x 63.5 | 278 x 177.8 x 63.5 | 278 x 177.8 x 63.5 | 278 x 177.8 x 63.5 |
| Working Temperature | -20~+70°C | |||
| Safety Standards | UL60950-1, TUV EN60950-1 approved | |||
| EMC Standards | EN55022 class B, EN61000-3-2,3 EN61000-4-2,3,4,5,6,8,11 | |||
