| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Enclosed Power Supplies |
Slim and Low profile (41mm)
Fanless and conduction-cooled design
Other features:
| Wattage | 1500 | 1512 |
| Input Voltage | 90 ~ 264VAC | 250 ~ 370VDC |
| Output Current | 62.5A | 31.5A |
| Output Voltage | 24V | 48V |
| Dimensions | 290*140*41mm (L*W*H) | 290*140*41mm (L*W*H) |
| Working Temperature | -30 ~ +70 (Refer to “Derating Curve") ℃ | |
| Safety Standards | UL62368-1, DEKRA BS EN/EN62368-1, EAC TP TC 004 approved | |
| EMC Standards | EN55032(CISPR32), EN61000-3-2,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11 | |
