True sine wave output (THD <3%)
Output Protections: Short circuit / Overload / Over temp.
Input Protections: Bat. Low alarm / Bat. Low shutdown / Reverse polarity / Over Voltage
Applications: Home appliance, power tools, office and portable equipment, vehicle and yacht…etc.
Other Features:
Wattage | 400 | 400 | 400 | |||
Input Voltage | 10.5-15VDC | 21.0-30VDC | 42.0-60VDC | |||
Output Current | 0 | 0 | 0 | |||
Output Voltage | 230 | 230 | 230 | |||
Output Voltage Options | Single | Single | Single | |||
DC output adjustment | N/A | N/A | N/A | |||
Dimensions | 205 x 158 x 67 | 205 x 158 x 67 | 205 x 158 x 67 | |||
Working Temperature | -30B0C~+45B0C | -30~+45B0C | -40B0C ~ +60B0C | |||
Safety Standards | Compliance to EN60950-1 | |||||
EMC Standards | Compliance to EN55022 class A, E-Mark, EN6100-4-2,3,8,ENV50204 |
