Mean Well DETN01-N Series DC-DC Power Supplies 1W

Download Datasheet
Models:
  • DETN01L-05N
  • DETN01L-12N
  • DETN01L-15N
  • DET01M-05N
  • DETN01M-12N
  • DETN01M-15N
  • DETN01N-05N
  • DETN01N-12N
  • DETN01N-15N
Manufacturer: Mean Well
Type: DC-DC Power Supplies

DETN01-N Series Features:

DETN01-N series is 1W isolated and unregulated module type DC-DC converter with SMD package.

Features:

  • SMD package with industry standard pinout
  • Operating temperature -40~100°C
  • High efficiency up to 83%
  • 3KVDC I/O isolation
  • Low cost
  • ±3.3Vo models available
  • 3 years warranty
Wattage 1 1 1 1 1 1 1 1 1
Input Voltage 4.5~5.5 4.5~5.5 4.5~5.5 10.8~13.2 10.8~13.2 10.8~13.2 21.6~26.4 21.6~26.4 21.6~26.4
Output Current ±10~100mA ±4.2~42mA ±3.4~34mA ±10~100mA ±4.2~42mA ±3.4~34mA ±10~100mA ±4.2~42mA ±3.4~34mA
Output Voltage ±5 ±12 ±15 ±5 ±12 ±15 ±5 ±12 ±15
Dimensions 15.24x10.9x9.1mm 15.24x10.9x9.1mm 15.24x10.9x9.1mm 15.24x10.9x9.1mm 15.24x10.9x9.1mm 15.24x10.9x9.1mm 15.24x10.9x9.1mm 15.24x10.9x9.1mm 15.24x10.9x9.1mm
Working Temperature -40~100°C
Safety Standards EAC TP TC 004 approved
EMC Standards BS EN/EN55032(CISPR32)
