Mean Well SD-350 Series DC-DC Power Supplies 350W

Download Datasheet
Models:
  • SD-350B-5
  • SD-350B-12
  • SD-350B-24
  • SD-350B-48
  • SD-350C-5
  • SD-350C-12
  • SD-350C-24
  • SD-350C-48
  • SD-350D-5
  • SD-350D-12
  • SD-350D-24
  • SD-350D-48
Manufacturer: Mean Well
Type: DC-DC Power Supplies

SD-350 Series Features:

2:1 wide input range

Protections: Short Circuit / Overload / Over voltage / Over temp.

Other Features:

  • 1500VAC I/O isolation
  • Built in EMI filter, low ripple noise
  • Forced air cooling by built in DC fan
  • 100% full load burn in test
  • 2 years warranty
Wattage 350 350 350 350 350 350 350 350 350 350 350 350
Input Voltage 19~36 19~36 19~36 19~36 36~72 36~72 36~72 36~72 72~144 72~ 72~144 72~144
Output Current 0~57.0 0~27.5 0~14.6 0~7.30 0~60.0 0~27.5 0~14.6 0~7.30 0~60.0 0~29.2 0~14.6 0~7.30
Output Voltage 5 12 24 48 5 12 24 48 5 12 24 48
Output Voltage Options Single Single Single Single Single Single Single Single Single Single Single Single
DC output adjustment 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V 5V: 4.5~5.5V, 12V: 11~16V, 24V: 23~30V, 48V: 43~53V
Dimensions 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50 215 x 115 x 50
Working Temperature -20 ~ +60°C (Refer to "Derating Curve")
Safety Standards Meet LVD, EN60950-1 CB approved by TUV ( D type only )
EMC Standards EN55022 class B, EN61000-4-2,3,4,5,6,8
