MEAN WELL
MEAN WELL SD-50 Series DC-DC Power Supplies 50–50.4W
Download Datasheet
| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | DC-DC Power Supplies |
SD-50 Series Features:
2:1 wide input range
Protections: Short Circuit / Overload / Over voltage
Other Features:
- 1500VAC I/O isolation
- Built in EMI filter, low ripple noise
- Cooling by free air convection
- 100% full load burn in test
- Low cost, high reliability
- 2 years warranty
| Wattage | 50 | 50 | 50 | 50.4 | 50.4 | 50.4 | 50.4 | 50.4 | 50.4 |
|---|---|---|---|---|---|---|---|---|---|
| Input Voltage | 9.2~18VDC | 19~36VDC | 36~72VDC | 9.2~18VDC | 19~36VDC | 36~72VDC | 9.2~18VDC | 19~36V | 36~72VDC |
| Output Current | 10A | 10A | 10A | 4.2A | 4.2A | 4.2A | 2.1A | 2.1A | 2.1A |
| Output Voltage | 5V | 5V | 5V | 12V | 12V | 12V | 24V | 24V | 24V |
| Dimensions | 159*97*38mm | 159*97*38mm | 159*97*38mm | 159*97*38mm | 159*97*38mm | 159*97*38mm | 159*97*38mm | 159*97*38mm | 159*97*38mm |
| Working Temperature | -10~60°C | ||||||||
| Safety Standards | Design refer to LVD, EAC TP TC 004, AS/NZS 62368.1 approved | ||||||||
| EMC Standards | Compliance to EN55032 (CISPR32) Class B, EAC TP TC 020 | ||||||||
