MEAN WELL NPB-1200 Series Chargers 1176–1209.6W

NPB-1200 Series Features:

NPB-1200 is a miniaturized, versatile, and ultra-wide voltage intelligent charge.

Features:

Auto ranging with ultra-wide charging voltage (10.5~21V, 21~42V, 42~80V)
Built-in CANBus protocol for control, setting and monitoring
Programmable 2/3 stage and charging curve via SBP-01
Manual setting for2/3 stage and 4 built-in charging curves via DIP S.W
Multiple protections: Short circuit/ Over voltage/ Over temperature/ Battery under voltage/ Battery reverse polarity(No damage)
Charger OK and Battery full signal
Temperature compensation function to prolong battery life )Lead-acid only)
-30~70°C wide operating temperature
Thermal controlled DC fan for noise reduction
Remote ON/OFF control
Smart programmer available
Carry handle accessory available
Comply with 62368-1 + 60335-1/-2-29 dual certification
Suitable for lead acid (Pb) and li-on batteries
3 years warranty

Spec	NPB-1200-12	NPB-1200-24	NPB-1200-48
Wattage	1176	1209.6	1209.6
Input Voltage	90~264VAC	90~264VAC	90~264VAC
Output Current	70	36	18
Output Voltage Options	Boost charge voltage 14.4V, Float charge voltage 13.8V	Boost charge voltage 28.8V, Float charge voltage 27.6V	Boost charge voltage 57.6V, Float charge voltage 55.2V
Dimensions	250x158x67mm	250x158x67mm	250x158x67mm
Working Temperature	-30~70°C
Safety Standards	CB IEC62368-, IEC60335-1/2-29, Dekra BS EN/EN62368-1, BS EN/EN60335-1/2-29, UL62368-1, EAC TP TC 004 approved
EMC Standards	BS EN/EN55032 (CISPR32), BS EN/EN55014-1, BS EN/EN61000-3-2, BS EN/EN61000-3-3
