MEAN WELL NPP-750 Series Chargers 722.4–759.36W

NPP-750 Series Features:

NPP-750 is a miniaturized dual-purpose charge and power supply.

Features:

Multi-function single unit battery charger or power supply operation modes selectable
Output voltage and current adjustable via potentiometer
3-stage charging curve for charging mode
-30~70° wide operating temperature
Multiple protections: short circuit/ Over load/ Over voltage/ Over temperature
Thermal controlled DC fan for noise reduction
Remote ON/OFF control
Comply with 62368-1+60335-1/-2-29 dual certification
Suitable for lead-acid (Pb) batteries
Carry handle accessories available (DS-carry handle, sold separately)
3 years warranty

Spec	NPP-750-12	NPP-750-24	NPP-750-48
Wattage	722.4	756	759.36
Input Voltage	90~264VAC	90~264VAC	90~264VAC
Output Current	43	22.5	11.3
Output Voltage	Boost charge 14.4V, Float charge 13.8V	Boost charge 28.8V, Float charge 27.6V	Booat charge 57.6V, Float charge 55.2V
Dimensions	230x158x67mm	230x158x67mm	230x158x67mm
Working Temperature	-30~70°C
Safety Standards	CB IEC62368-1, IEC60335-1/2-29, Dekra BS EN/EN62368-1, BS EN/EN60335-1/2-29, UL62368-1, EAC TP TC 004 approved
EMC Standards	BS EN/EN55032 (CISPR32), BS EN/EN55014-1, BS EN/EN61000-3-2, BS EN/EN61000-3-3
