Mean Well IRM-10 Series Open Frame Power Supplies 8–10W

Download Datasheet
Models:
  • IRM-10-3.3
  • IRM-10-5
  • IRM-10-12
  • IRM-10-15
  • IRM-10-24
Manufacturer: Mean Well
Type: Open Frame Power Supplies

IRM-10 Series Features:

No load power consumption <0.1W

Compact size

Protections: Short circuit/ Overload/ Over voltage

Other features:

  • Universal AC input/ full range
  • Cooling by free air convection
  • Isolation class II
  • 100% full load burn in test
  • High reliability
  • 3 years warranty
Wattage 8 10 10 10 10
Input Voltage 90~305VAC, 120~370VDC 90~305VAC, 120~370VDC 90~305VAC, 120~370VDC 90~305VAC, 120~370VDC 90~305VAC, 120~370VDC
Output Current 0~2.5 0~2.0 0~0.85 0~0.67 0~0.42
Output Voltage 3.3 5 12 15 24
Output Voltage Options Single Single Single Single Single
Dimensions 45.7x 25.4x 21.5 45.7x 25.4x 21.5 45.7x 25.4x 21.5 45.7x 25.4x 21.5 45.7x 25.4x 21.5
Working Temperature -30~+70°C
Safety Standards UL60950-1, TUV EN60950-1 approved
EMC Standards Compliance to to EN55022 (CISPR22) Class B, EN61000-3-2,-3, EN61000-4-2,3,4,5,6,8,11, EN55024, heavy industry level, criteria A
