| Models: |
|
| Manufacturer: | MEAN WELL |
| Type: | Open Frame Power Supplies |
Fixed switching frequency at 65kHz
Protections: Short circuit / Overload / Over voltage
Other features:
| Wattage | 65 | 45 |
| Input Voltage | 90~264VAC, 127~370VDC | 90~264VAC, 127~370VDC |
| Output Current | 0.4~6.0, 0.2~2.6 | 0.4~7.0, 0.2~3.2 |
| Output Voltage | 5, 24 | 5, 12 |
| Output Voltage Options | Dual | Dual |
| DC output adjustment | -5%~+10% rated output voltage | -5%~+10% rated output voltage |
| Dimensions | 127 x 76 x 42 | 127 x 76 x 42 |
| Working Temperature | -30~+60°C | |
| Safety Standards | UL60950-1, TUV EN60950-1 approved | |
| EMC Standards | EN55022 class B,EN61000-3-2,-3 , EN61000- 4-2,3,4,5,6,8,11 | |
